TPS77401DGKR
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Lead Free Positive GULL WING Linear Voltage Regulator IC -40C~125C 412mW 250mA 3mm
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.7961
≥1 USD $0.7961
≥10 USD $0.6536
≥100 USD $0.63365
≥500 USD $0.61275
≥1000 USD $0.5928
Inventory: 15799
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Technical
Input Bias Current 92μA
Voltage - Output (Max) 5.5V
Min Output Voltage 1.5V
Dropout Voltage 125mV
Reference Voltage 1.1834V
PSRR 55dB (1kHz)
Current - Quiescent (Iq) 125μA
Protection Features Over Current, Over Temperature, Reverse Polarity
Min Input Voltage 2.7V
Number of Regulators 1
Max Output Voltage 5.5V
Accuracy 2 %
Control Features Enable, Power Good
Quiescent Current 90μA
Output Configuration Positive
Max Output Current 250mA
Output Type Adjustable
Output Voltage 5.5V
Voltage - Input (Max) 10V
Number of Outputs 1
Pin Count 8
Base Part Number TPS77401
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Max Power Dissipation 412mW
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
