TPS77315DGKG4
RoHS
/
Package VSSOP
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
IC REG LDO 1.5V 0.25A 8VSSOP
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.041909
≥1 USD $1.041909
≥10 USD $0.982926
≥100 USD $0.927294
≥500 USD $0.874795
≥1000 USD $0.825281
Inventory: 1253
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 970μm
Technical
Line Regulation-Max (%/V) 0.0056%
Output Voltage Accuracy 2 %
Voltage Tolerance-Max 2%
Min Output Voltage 1.5V
Dropout Voltage1-Nom 1V
Dropout Voltage 200mV
Max Input Voltage 10V
Current - Input Bias 92μA
Min Input Voltage 2.7V
Output Voltage 1 1.5V
Voltage - Output 1.5V
Max Output Voltage 1.5V
Accuracy 2 %
Quiescent Current 90μA
Current - Output 250mA
Power Dissipation 412mW
Power Dissipation-Max 412mW
Polarity Positive
Max Output Current 250mA
Output Type Fixed
Number of Outputs 1
Pin Count 8
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Power Rating 412mW
Subcategory Other Regulators
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4
Packaging Rail/Tube
Physical
Number of Pins 8
Surface Mount YES
Package / Case VSSOP
