TPS76901DBVTG4
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS76901 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 5.5V 1.45mm 100mA 555mW
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 103808
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TR
Max Power Dissipation 555mW
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS76901
Pin Count 5
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 5.5V
Output Type Adjustable
Max Output Current 100mA
Output Configuration Positive
Power Dissipation 555mW
Quiescent Current 20μA
Control Features Enable
Accuracy 3 %
Max Output Voltage 5.5V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 28μA
PSRR 60dB (1kHz)
Reference Voltage 1.224V
Dropout Voltage 71mV
Dropout Voltage1-Nom 0.071V
Min Output Voltage 1.2V
Voltage - Output (Max) 5.5V
Input Bias Current 17μA
Output Voltage Accuracy 3 %
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
