TPS76750QDRG4

Texas Instruments
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Tape and Reel Surface Mount RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) voltage regulator linear 230mV 4.9mm 1A 904mW
PDF
/
Buying Options
Total Price: USD $14.77
Unit Price: USD $14.7668
≥1 USD $14.7668
≥10 USD $12.1163
≥100 USD $11.7382
≥500 USD $11.35915
≥1000 USD $10.9801
Inventory: 8210
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 3.9mm
Length 4.9mm

Technical

Output Voltage Accuracy 2 %
Min Current Limit 1.2A
Voltage Tolerance-Max 2%
Dropout Voltage1-Nom 380V
Dropout Voltage 230mV
Max Input Voltage 10V
Current - Input Bias 85μA
Min Input Voltage 2.7V
Output Voltage 1 5V
Voltage - Output 5V
Accuracy 2 %
Quiescent Current 125μA
Current - Output 1A
Power Dissipation 904mW
Power Dissipation-Max 904mW
Polarity Positive
Max Output Current 1A
Output Type Fixed
Number of Outputs 1
Pin Count 8
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Subcategory Other Regulators
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Tape and Reel

Physical

Number of Pins 8
Package / Case SOIC
Mount Surface Mount
