TPS76350QDBVRQ1
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS76350 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 180mV 1.45mm 150mA 555mW
PDF
/
Buying Options
Total Price: USD $1.02
Unit Price: USD $1.0208
≥1 USD $1.0208
≥10 USD $0.9152
≥100 USD $0.868384
≥500 USD $0.713416
≥1000 USD $0.666899
≥3000 USD $0.589371
Inventory: 28214
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TR
Max Power Dissipation 555mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS76350
Pin Count 5
Current - Supply (Max) 140μA
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 5V
Output Type Fixed
Max Output Current 150mA
Output Configuration Positive
Power Dissipation 555mW
Quiescent Current 80μA
Control Features Enable
Accuracy 3 %
Max Output Voltage 5V
Output Voltage 1 5V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 100μA
Voltage Dropout (Max) 0.3V @ 150mA
PSRR 60dB (1kHz)
Reference Voltage 1.192V
Dropout Voltage 180mV
Dropout Voltage1-Nom 0.3V
Min Output Voltage 5V
Voltage Tolerance-Max 4%
Min Current Limit 500mA
Input Bias Current 85μA
Output Voltage Accuracy 3 %
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
