TPS75733KC
RoHS
RoHS compliant
RoHS compliantPackage TO-220-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS75733 Tube Through Hole Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 150mV 4.7mm 3A -40C~125C
PDF
/
Buying Options
Total Price: USD $6.78
Unit Price: USD $6.776
≥1 USD $6.776
≥10 USD $6.12216
≥100 USD $5.837744
≥500 USD $5.068976
≥1000 USD $4.841126
≥3000 USD $4.413957
Inventory: 193
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 4.58mm
Width 8.51mm
Length 10.16mm
Height 4.7mm
Technical
Output Voltage Accuracy 3 %
Input Bias Current 125μA
Min Current Limit 5.5A
Voltage Tolerance-Max 3%
Min Output Voltage 3.3V
Dropout Voltage1-Nom 0.15V
Dropout Voltage 150mV
PSRR 62dB (100Hz)
Voltage Dropout (Max) 0.3V @ 3A
Current - Quiescent (Iq) 200μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.8V
Number of Regulators 1
Output Voltage 1 3.3V
Max Output Voltage 3.3V
Accuracy 3 %
Control Features Enable, Power Good
Quiescent Current 120μA
Output Configuration Positive
Max Output Current 3A
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Pin Count 3
Base Part Number TPS75733
Number of Functions 1
Terminal Position SINGLE
Technology PMOS
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount NO
Package / Case TO-220-5
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
