TPS75615KCG3
RoHS
RoHS compliant
RoHS compliantPackage TO-220-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive PMOS Linear Voltage Regulator IC -40C~125C 5A 4.7mm 250mV
PDF
/
Buying Options
Total Price: USD $2.79
Unit Price: USD $2.790949
≥1 USD $2.790949
≥10 USD $2.632972
≥100 USD $2.483938
≥500 USD $2.343337
≥1000 USD $2.210688
Inventory: 1344
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 4.58mm
Width 8.51mm
Length 10.16mm
Height 4.7mm
Technical
Output Voltage Accuracy 3 %
Input Bias Current 125μA
Min Current Limit 5.5A
Voltage Tolerance-Max 3%
Min Output Voltage 1.5V
Dropout Voltage1-Nom 0.25V
Dropout Voltage 250mV
PSRR 60dB (100Hz)
Current - Quiescent (Iq) 200μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.8V
Number of Regulators 1
Output Voltage 1 1.5V
Max Output Voltage 1.5V
Accuracy 3 %
Control Features Enable
Quiescent Current 120μA
Output Configuration Positive
Max Output Current 5A
Output Type Fixed
Output Voltage 1.5V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Pin Count 3
Base Part Number TPS75615
Number of Functions 1
Terminal Position SINGLE
Technology PMOS
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount NO
Package / Case TO-220-5
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
