TPS75515KTTT
RoHS
RoHS compliant
RoHS compliantPackage TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS75515 Cut Tape (CT) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 250mV 4.58mm 5A -40C~125C
PDF
/
Buying Options
Total Price: USD $6.76
Unit Price: USD $6.75925
≥1 USD $6.75925
≥10 USD $5.5461
≥100 USD $5.3732
≥500 USD $5.19935
≥1000 USD $5.02645
Inventory: 1125
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 8.42mm
Length 10.16mm
Height 4.58mm
Technical
Output Voltage Accuracy 3 %
Input Bias Current 125μA
Nominal Output Voltage 1.5V
Min Current Limit 5.5A
Voltage Tolerance-Max 3%
Min Output Voltage 1.5V
Dropout Voltage1-Nom 1.3V
Dropout Voltage 250mV
PSRR 60dB (100Hz)
Current - Quiescent (Iq) 200μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.8V
Number of Regulators 1
Output Voltage 1 1.5V
Max Output Voltage 1.5V
Accuracy 3 %
Control Features Enable, Power Good
Quiescent Current 120μA
Output Configuration Positive
Min Supply Voltage 2.8V
Max Supply Voltage 5.5V
Max Output Current 5A
Output Type Fixed
Output Voltage 1.5V
Number of Outputs 1
Pin Count 4
Base Part Number TPS75515
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Technology PMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e3
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Mounting Type Surface Mount
Alternative Model
