TPS75401QPWPR
RoHS
RoHS compliant
RoHS compliantPackage 20-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS75401 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 210mV 1.2mm 2A 7.2W
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.39685
Inventory: 1265
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 6.5mm
Height 1.2mm
Technical
Output Voltage Accuracy 2 %
Input Bias Current 75μA
Voltage - Output (Max) 5V
Min Output Voltage 1.5V
Dropout Voltage1-Nom 0.21V
Dropout Voltage 210mV
Reference Voltage 1.1834V
PSRR 60dB (100Hz)
Current - Quiescent (Iq) 125μA
Protection Features Over Current, Over Temperature, Reverse Polarity
Min Input Voltage 2.7V
Number of Regulators 1
Max Output Voltage 5V
Accuracy 2 %
Control Features Enable, Power Good, Reset Output
Quiescent Current 70μA
Power Dissipation 7.2W
Output Configuration Positive
Max Output Current 2A
Output Type Adjustable
Output Voltage 5V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Pin Count 20
Base Part Number TPS75401
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Max Power Dissipation 7.2W
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-PowerTSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
Alternative Model
