TPS75401QPWP
RoHS
RoHS compliant
RoHS compliantPackage 20-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS75401 Tube Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 210mV 1.2mm 2A 7.2W
PDF
/
Buying Options
Total Price: USD $5.38
Unit Price: USD $5.3768
≥1 USD $5.3768
≥10 USD $4.8576
≥100 USD $4.631563
≥500 USD $4.0216
≥1000 USD $3.840857
≥3000 USD $3.50196
Inventory: 154
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 6.5mm
Height 1.2mm
Technical
Output Voltage Accuracy 2 %
Input Bias Current 75μA
Voltage - Output (Max) 5V
Min Output Voltage 1.5V
Dropout Voltage1-Nom 0.21V
Dropout Voltage 210mV
Reference Voltage 1.1834V
PSRR 60dB (100Hz)
Current - Quiescent (Iq) 125μA
Protection Features Over Current, Over Temperature, Reverse Polarity
Min Input Voltage 2.7V
Number of Regulators 1
Max Output Voltage 5V
Accuracy 2 %
Control Features Enable, Power Good, Reset Output
Quiescent Current 70μA
Power Dissipation 7.2W
Output Configuration Positive
Max Output Current 2A
Output Type Adjustable
Output Voltage 5V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Pin Count 20
Base Part Number TPS75401
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Max Power Dissipation 7.2W
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-PowerTSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
Alternative Model
