TPS75115QPWPRG4

Texas Instruments
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description IC REG LINEAR 1.5V 1.5A 20HTSSOP
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.36465
≥1 USD $5.36465
≥10 USD $4.40135
≥100 USD $4.26455
≥500 USD $4.1268
≥1000 USD $3.98905
Inventory: 1528
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 4.4mm
Length 6.5mm

Technical

Line Regulation-Max (%/V) 0.00345%
Voltage Tolerance-Max 2%
Min Output Voltage 1.5V
Dropout Voltage 160mV
Max Input Voltage 5.5V
Current - Input Bias 75μA
Min Input Voltage 2.7V
Output Voltage 1 1.5V
Voltage - Output 1.5V
Max Output Voltage 1.5V
Accuracy 2 %
Quiescent Current 70μA
Current - Output 1.5A
Power Dissipation-Max 7.2W
Polarity Positive
Max Output Current 1.5A
Output Type Fixed
Number of Outputs 1
Pin Count 20
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2
JESD-609 Code e4

Physical

Number of Pins 20
Surface Mount YES
