TPS74525PQWDRVRQ1
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS74525 6-WDFN Exposed Pad Surface Mount Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 2.5375V 2mm 500mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.70928
≥100 USD $0.673376
≥500 USD $0.553256
≥1000 USD $0.517194
≥3000 USD $0.457037
Inventory: 1157
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 2mm
Length 2mm
Height Seated (Max) 0.8mm
Technical
Output Voltage1-Min 2.4625V
Output Voltage1-Max 2.5375V
Dropout Voltage1-Nom 0.225V
PSRR 57dB ~ 35dB (1kHz ~ 1MHz)
Voltage Dropout (Max) 0.105V @ 500mA
Current - Quiescent (Iq) 36μA
Protection Features Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Number of Regulators 1
Voltage - Output (Min/Fixed) 2.5V
Input Voltage (Min) 3V
Output Voltage 1 2.5V
Control Features Enable, Power Good
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 6V
Number of Outputs 1
JESD-30 Code S-PDSO-N6
Base Part Number TPS74525
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
