TPS74301RGWRG4
RoHS
RoHS compliant
RoHS compliantPackage 20-VQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS74301 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 55mV 1mm 1.5A 3.28W
PDF
/
Buying Options
Total Price: USD $2.16
Unit Price: USD $2.164301
≥1 USD $2.164301
≥10 USD $2.041793
≥100 USD $1.926214
≥500 USD $1.817186
≥1000 USD $1.71433
Inventory: 1175
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 20-VQFN Exposed Pad
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TR
Max Power Dissipation 2.74W
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS74301
Pin Count 20
Current - Supply (Max) 1.5mA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 3.6V
Output Type Adjustable
Max Output Current 1.5A
Output Configuration Positive
Power Dissipation 3.28W
Quiescent Current 3mA
Control Features Enable, Power Good, Tracking
Accuracy 1 %
Max Output Voltage 3.6V
Voltage - Output (Min/Fixed) 0.8V
Number of Regulators 1
Min Input Voltage 800mV
Protection Features Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 115μA
Voltage Dropout (Max) 0.12V @ 1.5A
PSRR 73dB ~ 42dB (1kHz ~ 800kHz)
Reference Voltage 804mV
Dropout Voltage 55mV
Dropout Voltage1-Nom 0.055V
Min Output Voltage 800mV
Min Current Limit 1.8A
Input Bias Current 2mA
Output Voltage Accuracy 1 %
Dimensions
Height 1mm
Length 5mm
Width 5mm
Thickness 900μm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
