TPS7425DG4

Texas Instruments
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description SOIC RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) DUAL voltage regulator linear 170mV 1.58mm 200mA 904mW
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.153932
≥1 USD $2.153932
≥10 USD $2.03202
≥100 USD $1.917
≥500 USD $1.808482
≥1000 USD $1.706114
Inventory: 1311
Minimum: 1
-
+

Technical Details

Physical

Package / Case SOIC
Surface Mount YES
Number of Pins 8

Technical

JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Other Regulators
Power Rating 497mW
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Pin Count 8
Number of Outputs 1
Output Type Fixed
Max Output Current 200mA
Polarity Positive
Power Dissipation-Max 904mW
Power Dissipation 904mW
Current - Output 200mA
Quiescent Current 1μA
Accuracy 3 %
Max Output Voltage 2.5V
Voltage - Output 2.5V
Output Voltage 1 2.5V
Min Input Voltage 2.5V
Current - Input Bias 80μA
Max Input Voltage 7V
Dropout Voltage 170mV
Min Output Voltage 2.5V
Voltage Tolerance-Max 3%
Output Voltage Accuracy 3 %

Dimensions

Height 1.58mm
Length 4.9mm
Width 3.91mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
