TPS73632DBVTG4
RoHS
/
Package SOT-23-5
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
IC REG LDO 3.2V 0.4A SOT23-5
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.389901
≥1 USD $1.389901
≥10 USD $1.311214
≥100 USD $1.236993
≥500 USD $1.166976
≥1000 USD $1.100922
Inventory: 6387
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOT-23-5
Surface Mount YES
Number of Pins 5
Technical
JESD-609 Code e4
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Pin Count 5
Number of Outputs 1
Output Type Fixed
Max Output Current 400mA
Polarity Positive
Power Dissipation-Max 560mW
Current - Output 400mA
Quiescent Current 300μA
Accuracy 1 %
Max Output Voltage 3.2V
Voltage - Output 3.2V
Output Voltage 1 3.2V
Min Input Voltage 1.7V
Current - Input Bias 300μA
Max Input Voltage 5.5V
Dropout Voltage 75mV
Dropout Voltage1-Nom 0.075V
Min Output Voltage 3.2V
Voltage Tolerance-Max 1%
Min Current Limit 400mA
Dimensions
Length 2.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
