TPS7348QPWLE
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead GULL WING Not Qualified BICMOS voltage regulator linear -40C 340muA 6.5mm 270mV
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.6336
≥1 USD $0.6336
Inventory: 1087
Minimum: 1
-
+
Technical Details
Physical
Package / Case TSSOP
Surface Mount YES
Number of Pins 8
Technical
Pbfree Code no
Number of Terminations 20
ECCN Code EAR99
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
JESD-30 Code R-PDSO-G20
Number of Outputs 1
Qualification Status Not Qualified
Operating Temperature (Max) 125°C
Operating Temperature (Min) -40°C
Quiescent Current 340μA
Voltage - Output 4.85V
Output Voltage 1 4.85V
Input Voltage (Min) 5.2V
Input Voltage (Max) 10V
Dropout Voltage 270mV
Dropout Voltage1-Nom 0.15V
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage Tolerance-Max 2.06%
Output Current1-Max 0.5A
Operating Temperature TJ-Max 125°C
Input Voltage Absolute-Max 10V
Adjustability FIXED
Load Regulation-Max(%) 0.13%
Line Regulation-Max (%/V) 0.037%
Operating Temperature TJ-Min -40°C
Dimensions
Height Seated (Max) 1.2mm
Length 6.5mm
Width 4.4mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
