TPS73433DRVT
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS73433 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 125mV 800mum 200mA 1.54W
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
≥10 USD $1.2584
≥100 USD $1.194688
≥500 USD $0.9812
Inventory: 1158
Minimum: 1
-
+
Technical Details
Technical
Operating Temperature -40°C~125°C
Output Voltage Accuracy 1 %
Input Bias Current 44μA
Min Current Limit 300mA
Voltage Tolerance-Max 2%
Min Output Voltage 3.3V
Dropout Voltage1-Nom 0.125V
Dropout Voltage 125mV
PSRR 60dB ~ 28dB (100Hz ~ 100kHz)
Voltage Dropout (Max) 0.22V @ 250mA
Current - Quiescent (Iq) 65μA
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 3.3V
Max Output Voltage 3.3V
Accuracy 2 %
Control Features Enable
Quiescent Current 40μA
Current - Output 250mA
Power Dissipation 1.54W
Output Configuration Positive
Max Output Current 200mA
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 6.5V
Number of Outputs 1
Pin Count 6
Base Part Number TPS73433
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 1.54W
Packing Method TR
Power Rating 1.54W
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Surface Mount YES
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 750μm
Width 2mm
Length 2mm
Height 800μm
