TPS73250DBVR
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS73250 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit Reverse Polarity voltage regulator linear 40mV 1.45mm 250mA 560mW
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.3112
≥1 USD $1.3112
≥10 USD $1.1748
≥100 USD $1.114784
≥500 USD $0.915816
≥1000 USD $0.856099
≥3000 USD $0.756554
Inventory: 5487
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
Technical
Output Voltage Accuracy 0.5 %
Input Bias Current 400μA
Min Current Limit 250mA
Voltage Tolerance-Max 1%
Min Output Voltage 5V
Dropout Voltage1-Nom 0.04V
Dropout Voltage 40mV
PSRR 58dB ~ 37dB (100Hz ~ 10kHz)
Voltage Dropout (Max) 0.15V @ 250mA
Current - Quiescent (Iq) 550μA
Protection Features Over Current, Over Temperature, Short Circuit, Reverse Polarity
Min Input Voltage 1.7V
Number of Regulators 1
Output Voltage 1 5V
Max Output Voltage 5V
Accuracy 1 %
Control Features Enable
Quiescent Current 400μA
Power Dissipation 560mW
Output Configuration Positive
Max Output Current 250mA
Output Type Fixed
Output Voltage 5V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Current - Supply (Max) 950μA
Pin Count 5
Base Part Number TPS73250
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 560mW
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 23 hours ago)
Factory Lead Time 6 Weeks
