TPS72616DCQ
RoHS
RoHS compliant
RoHS compliantPackage SOT-223-6
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS72616 Tube Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 280mV 1.8mm 1A -40C~125C
PDF
/
Buying Options
Total Price: USD $9.85
Unit Price: USD $9.849376
≥1 USD $9.849376
≥200 USD $3.811349
≥500 USD $3.677433
≥1000 USD $3.611788
Inventory: 1593
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.6mm
Width 3.5mm
Length 6.5mm
Height 1.8mm
Technical
Min Current Limit 1.1A
Voltage Tolerance-Max 2%
Min Output Voltage 1.6V
Dropout Voltage1-Nom 0.17V
Dropout Voltage 280mV
Reference Voltage 1.22V
PSRR 60dB (1kHz)
Voltage Dropout (Max) 0.32V @ 1A
Current - Quiescent (Iq) 120μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 1.8V
Number of Regulators 1
Output Voltage 1 1.6V
Max Output Voltage 1.6V
Accuracy 2 %
Control Features Enable, Reset
Quiescent Current 70μA
Output Configuration Positive
Max Output Current 1A
Output Type Fixed
Output Voltage 1.6V
Voltage - Input (Max) 6V
Number of Outputs 1
Current - Supply (Max) 300μA
Pin Count 6
Base Part Number TPS72616
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Surface Mount YES
Package / Case SOT-223-6
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 8 Weeks
