TPS72515DCQG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package SOT-223-6
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description TPS72515 Tube Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 170mV 1.8mm 1A -40C~125C
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.21255
≥1 USD $2.21255
≥10 USD $1.81545
≥100 USD $1.75845
≥500 USD $1.70145
≥1000 USD $1.6454
Inventory: 1262
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)

Physical

Mounting Type Surface Mount
Package / Case SOT-223-6
Surface Mount YES
Number of Pins 6

Technical

Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 6
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS72515
Pin Count 6
Current - Supply (Max) 325μA
Number of Outputs 1
Output Voltage 1.5V
Output Type Fixed
Max Output Current 1A
Voltage 1.5V
Max Supply Voltage 6V
Min Supply Voltage 1.8V
Output Configuration Positive
Quiescent Current 70μA
Control Features Enable, Reset
Accuracy 2 %
Max Output Voltage 1.5V
Output Voltage 1 1.5V
Number of Regulators 1
Min Input Voltage 1.8V
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 225μA
Voltage Dropout (Max) 0.32V @ 1A
PSRR 60dB (1kHz)
Reference Voltage 1.263V
Dropout Voltage 170mV
Dropout Voltage1-Nom 0.17V
Min Output Voltage 1.5V
Min Current Limit 1.1A
Nominal Output Voltage 1.5V
Input Bias Current 75μA

Dimensions

Height 1.8mm
Length 6.5mm
Width 3.5mm
Thickness 1.6mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
