TPS7201QPW
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive GULL WING Linear Voltage Regulator IC -40C~125C 525mW 250mA 1.2mm
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 24003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1mm
Width 4.4mm
Length 3mm
Height 1.2mm
Technical
Load Regulation-Max(%) 3.62%
Output Voltage Accuracy 3 %
Input Bias Current 180μA
Voltage - Output (Max) 9.75V
Min Output Voltage 1.2V
Dropout Voltage1-Nom 0.56V
Dropout Voltage 190mV
Reference Voltage 1.188V
PSRR 85dB ~ 50dB (10Hz ~ 1MHz)
Voltage Dropout (Max) 0.2V @ 350mA
Current - Quiescent (Iq) 80μA
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Min Input Voltage 3V
Number of Regulators 1
Max Output Voltage 9.75V
Accuracy 3 %
Control Features Enable
Quiescent Current 180μA
Power Dissipation 525mW
Output Configuration Positive
Max Output Current 250mA
Output Type Adjustable
Output Voltage 9.75V
Voltage - Input (Max) 10V
Number of Outputs 1
Pin Count 8
Base Part Number TPS7201
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Max Power Dissipation 525mW
Power Rating 336mW
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
