TPS72015YZUT
RoHS
RoHS compliant
RoHS compliantPackage 5-UFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS72015 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 110mV 625mum 300mA 403mW
PDF
/
Buying Options
Total Price: USD $1.27
Unit Price: USD $1.2672
≥1 USD $1.2672
≥10 USD $1.12992
≥100 USD $1.072544
Inventory: 421
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.616mm
Length 1.25mm
Height 625μm
Technical
Output Voltage Accuracy 2 %
Input Bias Current 38μA
Nominal Output Voltage 1.5V
Min Current Limit 420mA
Min Output Voltage 1.5V
Dropout Voltage1-Nom 0.11V
Dropout Voltage 110mV
PSRR 85dB ~ 50dB (10Hz ~ 1MHz)
Voltage Dropout (Max) 0.2V @ 350mA
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Min Input Voltage 1.1V
Number of Regulators 1
Output Voltage 1 1.5V
Max Output Voltage 1.5V
Accuracy 2 %
Control Features Enable
Quiescent Current 30μA
Current - Output 350mA
Power Dissipation 403mW
Output Configuration Positive
Max Output Current 300mA
Output Type Fixed
Output Voltage 1.5V
Voltage - Input (Max) 4.5V
Number of Outputs 1
Current - Supply (Max) 80μA
Pin Count 5
Base Part Number TPS72015
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology BICMOS
Max Power Dissipation 403mW
Power Rating 1.58W
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 5
Surface Mount YES
Package / Case 5-UFBGA, DSBGA
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
