TPS72011DRVT image
Favorite
TPS72011DRVT image
Favorite

TPS72011DRVT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description TPS72011 Cut Tape (CT) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 110mV 800mum 350mA 1.58W
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.24256
≥100 USD $1.179552
≥500 USD $0.968968
Inventory: 1152
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-WDFN Exposed Pad
Number of Pins 6
Weight 9.695537mg

Technical

Operating Temperature -40°C~125°C TJ
Packaging Cut Tape (CT)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Power Rating 1.58W
Max Power Dissipation 1.58W
Technology BICMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TPS72011
Pin Count 6
Current - Supply (Max) 80μA
Number of Outputs 1
Voltage - Input (Max) 4.5V
Output Voltage 1.1V
Output Type Fixed
Max Output Current 350mA
Operating Supply Current 38μA
Output Configuration Positive
Quiescent Current 38μA
Control Features Enable
Accuracy 2 %
Output Voltage 1 1.1V
Number of Regulators 1
Min Input Voltage 1.1V
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Voltage Dropout (Max) 0.2V @ 350mA
PSRR 85dB ~ 50dB (10Hz ~ 1MHz)
Dropout Voltage 110mV
Dropout Voltage1-Nom 0.11V
Min Current Limit 420mA
Nominal Output Voltage 1.1V

Dimensions

Height 800μm
Length 2mm
Width 2mm
Thickness 750μm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Alternative Model

LTC1296CCSW#TR

LTC1296CCSW#TR

Analog Devices, Inc.

Recommended For You

LT1469ACDF#PBF
