TPS71H01QPWPRG4

Texas Instruments
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 0.5A 20HTSSOP
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.154532
≥1 USD $2.154532
≥10 USD $2.032584
≥100 USD $1.917529
≥500 USD $1.80899
≥1000 USD $1.70659
Inventory: 1314
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 4.4mm
Length 6.5mm

Technical

Voltage Reference 1.178V
Line Regulation-Max (%/V) 0.29
Load Regulation-Max(%) 4.6%
Min Output Voltage 1.2V
Dropout Voltage1-Nom 1.32V
Dropout Voltage 146mV
Max Input Voltage 10V
Current - Input Bias 285μA
Min Input Voltage 2.5V
Voltage - Output 9.75V
Max Output Voltage 9.75V
Accuracy 3 %
Quiescent Current 280μA
Current - Output 500mA
Power Dissipation-Max 700mW
Polarity Positive
Max Output Current 500mA
Output Type Adjustable
Number of Outputs 1
Pin Count 20
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Subcategory Other Regulators
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel

Physical

Number of Pins 20
Surface Mount YES
