TPS71825-12DRVT
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS71825 Tape & Reel (TR) Surface Mount Over Current Over Temperature Under Voltage Lockout (UVLO) voltage regulator linear 230mV 800mum 200mA 1.053W
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.78288
≥100 USD $1.682208
≥500 USD $1.43308
Inventory: 653
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 750μm
Width 2mm
Length 2mm
Height 800μm
Technical
Output Voltage 2 1.2V
Current - Output 2 200mA
Output Voltage Accuracy 3 %
Input Bias Current 90μA
Min Current Limit 240mA
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 0.23V
Dropout Voltage 230mV
Current - Output 1 200mA
PSRR 63dB ~ 44dB (100Hz ~ 1MHz)
Current - Quiescent (Iq) 160μA
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Min Input Voltage 2.7V
Number of Regulators 2
Voltage - Output (Min/Fixed) 2.5V 1.2V
Voltage - Output 2 1.2V
Output Voltage 1 2.5V
Max Output Voltage 2.5V
Accuracy 3 %
Control Features Enable
Quiescent Current 90μA
Power Dissipation 1.053W
Output Configuration Positive
Nominal Supply Current 90μA
Min Supply Voltage 2.7V
Max Supply Voltage 6.5V
Voltage - Output 1 2.5V
Max Output Current 200mA
Output Type Fixed
Output Voltage 1.2V
Number of Outputs 2
Current - Supply (Max) 250μA
Pin Count 6
Base Part Number TPS71825
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 1.053W
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Surface Mount YES
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
Alternative Model
