TPS71712DCKT
RoHS
RoHS compliant
RoHS compliantPackage 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive SMD/SMT Linear Voltage Regulator IC -40C~125C 320mW 150mA 1.1mm
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.3552
≥1 USD $1.3552
≥10 USD $1.20912
≥100 USD $1.147168
≥500 USD $0.942392
Inventory: 715
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 900μm
Width 1.25mm
Length 2mm
Height 1.1mm
Technical
Output Voltage Accuracy 3 %
Input Bias Current 50μA
Nominal Output Voltage 1.2V
Min Current Limit 200mA
Voltage Tolerance-Max 3%
Min Output Voltage 1.2V
Dropout Voltage1-Nom 0.17V
Dropout Voltage 170mV
PSRR 70dB ~ 45dB (100Hz ~ 1MHz)
Voltage Dropout (Max) 0.3V @ 150mA
Current - Quiescent (Iq) 80μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Min Input Voltage 2.5V
Number of Regulators 1
Output Voltage 1 1.2V
Max Output Voltage 1.2V
Accuracy 3 %
Control Features Enable
Quiescent Current 50μA
Power Dissipation 320mW
Output Configuration Positive
Min Supply Voltage 2.5V
Max Supply Voltage 6.5V
Max Output Current 150mA
Output Type Fixed
Output Voltage 1.2V
Number of Outputs 1
Current - Supply (Max) 100μA
Pin Count 5
Base Part Number TPS71712
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Max Power Dissipation 320mW
Packing Method TR
Power Rating 320mW
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 5
Surface Mount YES
Package / Case 5-TSSOP, SC-70-5, SOT-353
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
