TPS7150QDRG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
SOIC RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) DUAL voltage regulator linear 146mV 4.9mm 500mA 725mW
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14985
≥1 USD $2.14985
≥10 USD $1.76415
≥100 USD $1.70905
≥500 USD $1.65395
≥1000 USD $1.59885
Inventory: 1718
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Number of Pins 8
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Pin Count 8
Number of Outputs 1
Output Type Fixed
Max Output Current 500mA
Polarity Positive
Power Dissipation-Max 725mW
Current - Output 500mA
Quiescent Current 280μA
Accuracy 2 %
Max Output Voltage 5V
Line Regulation-Max (%/V) 0.032%
Voltage Tolerance-Max 2%
Min Output Voltage 5V
Dropout Voltage1-Nom 0.146V
Dropout Voltage 146mV
Max Input Voltage 10V
Current - Input Bias 285μA
Min Input Voltage 5.3V
Output Voltage 1 5V
Voltage - Output 5V
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
