TPS7148QPWLE
RoHS
/
Package TSSOP
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead GULL WING Not Qualified PMOS voltage regulator linear 125C 0.5A 6.5mm 4.95V
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.83265
≥1 USD $4.83265
≥10 USD $3.9653
≥100 USD $3.8418
≥500 USD $3.71735
≥1000 USD $3.59385
Inventory: 1275
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.4mm
Length 6.5mm
Height Seated (Max) 1.2mm
Technical
Operating Temperature TJ-Min -40°C
Line Regulation-Max (%/V) 0.037%
Load Regulation-Max(%) 0.13%
Adjustability FIXED
Input Voltage Absolute-Max 10V
Operating Temperature TJ-Max 125°C
Output Current1-Max 0.5A
Voltage Tolerance-Max 2%
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Voltage1-Min 4.75V
Output Voltage1-Max 4.95V
Dropout Voltage1-Nom 0.25V
Dropout Voltage 235mV
Input Voltage (Max) 10V
Input Voltage (Min) 5.2V
Output Voltage 1 4.85V
Quiescent Current 280μA
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PDSO-G20
Pin Count 20
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology PMOS
Packing Method TAPE&REEL (LEFT)
Subcategory Other Regulators
HTS Code 8542.39.00.01
ECCN Code EAR99
Number of Terminations 20
Pbfree Code no
Physical
Surface Mount YES
Package / Case TSSOP
