TPS70927QDRVRQ1
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS70927 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 245mV 800mum 150mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.03
Unit Price: USD $1.026267
≥1 USD $1.026267
≥10 USD $0.968178
≥100 USD $0.913377
≥500 USD $0.861673
≥1000 USD $0.8129
Inventory: 1532
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 750μm
Width 2mm
Length 2mm
Height 800μm
Technical
Min Current Limit 200mA
Dropout Voltage1-Nom 0.245V
Dropout Voltage 245mV
PSRR 80dB ~ 52dB (10Hz ~ 1kHz)
Current - Quiescent (Iq) 2.05μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Number of Regulators 1
Output Voltage 1 2.7V
Control Features Enable
Quiescent Current 1μA
Current - Output 150mA
Output Configuration Positive
Output Type Fixed
Output Voltage 2.7V
Voltage - Input (Max) 30V
Number of Outputs 1
Current - Supply (Max) 350μA
Base Part Number TPS70927
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
