TPS70348PWP
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS70348 Tube Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 250mV 1.2mm 1A 4.115W
PDF
/
Buying Options
Total Price: USD $6.56
Unit Price: USD $6.5648
≥1 USD $6.5648
≥10 USD $5.92768
≥100 USD $5.65195
≥500 USD $4.90754
≥1000 USD $4.686994
≥3000 USD $4.273447
Inventory: 600
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Surface Mount YES
Number of Pins 24
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 24
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Max Power Dissipation 4.115W
Technology PMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPS70348
Pin Count 24
Number of Outputs 2
Voltage - Input (Max) 6V
Output Voltage 1.5V
Output Type Fixed
Max Output Current 1A
Voltage - Output 1 3.3V
Output Configuration Positive
Power Dissipation 4.115W
Current - Output 1A 2A
Quiescent Current 180μA
Control Features Enable, Power Good, Reset, Sequencing
Accuracy 2 %
Max Output Voltage 3.3V
Output Voltage 1 3.3V
Voltage - Output 2 1.5V
Voltage - Output (Min/Fixed) 3.3V 1.5V
Number of Regulators 2
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 250μA
Voltage Dropout (Max) 0.25V @ 1A -
PSRR 65dB (1kHz), 60dB (1kHz)
Current - Output 1 1A
Dropout Voltage 250mV
Dropout Voltage1-Nom 0.16V
Min Output Voltage 3.3V
Power Supply Rejection Ratio (PSRR) 60dB
Voltage Tolerance-Max 2%
Input Bias Current 185μA
Output Voltage Accuracy 2 %
Current - Output 2 2A
Output Voltage 2 1.5V
Dimensions
Height 1.2mm
Length 7.8mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
