TLV76750DRVT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description TLV76750 Tape & Reel (TR) Surface Mount Over Current Over Temperature UVLO voltage regulator linear 0.9V 2mm 1A -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.37622
≥1 USD $0.37622
≥10 USD $0.35492
≥100 USD $0.33483
≥500 USD $0.31588
≥1000 USD $0.298
≥3000 USD $0.28113
Inventory: 3933
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 2mm
Length 2mm
Height Seated (Max) 0.8mm

Technical

Dropout Voltage1-Nom 0.9V
PSRR 70dB (120Hz)
Voltage Dropout (Max) 0.9V @ 1A
Current - Quiescent (Iq) 80μA
Protection Features Over Current, Over Temperature, UVLO
Number of Regulators 1
Voltage - Output (Min/Fixed) 5V
Input Voltage (Min) 2.5V
Output Voltage 1 5V
Control Features Enable
Current - Output 1A
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 16V
Number of Outputs 1
Current - Supply (Max) 1.5mA
JESD-30 Code S-PDSO-N6
Base Part Number TLV76750
Reach Compliance Code compliant
Terminal Pitch 0.65mm
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Technology BIPOLAR
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2
Part Status Active
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ

Physical

Surface Mount YES
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 6 Weeks
