TLV76701DRVT
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Positive NO LEAD S-PDSO-N6 Linear Voltage Regulator IC -40C~125C TJ 1A 2mm 0.9V
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.924
≥1 USD $0.924
≥10 USD $0.82896
≥100 USD $0.786368
≥500 USD $0.646008
Inventory: 3233
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-WDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 6
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TLV76701
JESD-30 Code S-PDSO-N6
Current - Supply (Max) 1.5mA
Number of Outputs 1
Voltage - Input (Max) 16V
Output Type Adjustable
Output Configuration Positive
Current - Output 1A
Control Features Enable
Voltage - Output (Min/Fixed) 0.8V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 80μA
Voltage Dropout (Max) 1.4V @ 1A
PSRR 70dB (120Hz)
Dropout Voltage1-Nom 0.9V
Output Voltage1-Min 0.8V
Voltage - Output (Max) 13.6V
Dimensions
Height Seated (Max) 0.8mm
Length 2mm
Width 2mm
Compliance
RoHS Status ROHS3 Compliant
