TLV73312PDQNR
RoHS
RoHS compliant
RoHS compliantPackage 4-XDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TLV73312 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 122mV 400mum 300mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.2376
≥1 USD $0.2376
≥10 USD $0.17512
≥100 USD $0.15312
≥500 USD $0.099088
≥1000 USD $0.082016
≥3000 USD $0.065613
Inventory: 1996
Minimum: 1
-
+
Technical Details
Technical
Quiescent Current 34μA
Control Features Enable
Output Voltage 1 1.2V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 60μA
Voltage Dropout (Max) 0.45V @ 300mA
PSRR 68dB ~ 28dB (100Hz ~ 100kHz)
Dropout Voltage 122mV
Dropout Voltage1-Nom 0.122V
Min Current Limit 360mA
Current - Output 300mA
Output Configuration Positive
Output Type Fixed
Output Voltage 1.2V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Base Part Number TLV73312
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Dimensions
Height 400μm
Length 1mm
Width 1mm
Thickness 370μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 4
Package / Case 4-XDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 6 Weeks
