TLV71209DBVT
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TLV71209 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 260mV 1.45mm 300mA 500mW
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.0472
≥1 USD $1.0472
≥10 USD $0.93632
≥100 USD $0.888448
≥500 USD $0.729784
Inventory: 488
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Power Rating 555mW
Packing Method TR
Max Power Dissipation 500mW
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number TLV71209
Pin Count 5
Current - Supply (Max) 370μA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 900mV
Output Type Fixed
Max Output Current 300mA
Output Configuration Positive
Power Dissipation 500mW
Quiescent Current 35μA
Control Features Enable
Accuracy 2 %
Max Output Voltage 900mV
Output Voltage 1 0.9V
Voltage - Output (Min/Fixed) 0.9V
Number of Regulators 1
Min Input Voltage 2V
Protection Features Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 55μA
PSRR 68dB (1kHz)
Dropout Voltage 260mV
Dropout Voltage1-Nom 0.26V
Min Output Voltage 900mV
Power Supply Rejection Ratio (PSRR) 68dB
Voltage Tolerance-Max 2%
Min Current Limit 320mA
Nominal Output Voltage 900mV
Output Voltage Accuracy 2 %
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
