TLV7103318DSER
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TLV7103318 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit Under Voltage Lockout (UVLO) voltage regulator linear 140mV 800mum 200mA 585mW
PDF
/
Buying Options
Total Price: USD $0.61
Unit Price: USD $0.6072
≥1 USD $0.6072
≥10 USD $0.53416
≥100 USD $0.5016
≥500 USD $0.409288
≥1000 USD $0.380125
≥3000 USD $0.323523
Inventory: 777
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 750μm
Width 1.5mm
Length 1.5mm
Height 800μm
Technical
Output Voltage 2 1.8V
Output Voltage Accuracy 2 %
Min Current Limit 220mA
Voltage Tolerance-Max 2%
Min Output Voltage 700mV
Dropout Voltage1-Nom 0.15V
Dropout Voltage 140mV
PSRR 80dB ~ 50dB (10Hz ~ 100kHz)
Voltage Dropout (Max) 0.2V @ 200mA -
Current - Quiescent (Iq) 110μA
Protection Features Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
Min Input Voltage 2V
Number of Regulators 2
Voltage - Output (Min/Fixed) 3.3V 1.8V
Output Voltage 1 3.3V
Max Output Voltage 4.8V
Accuracy 2 %
Control Features Enable
Quiescent Current 30μA
Output Configuration Positive
Max Output Current 200mA
Output Type Fixed
Output Voltage 1.8V
Voltage - Input (Max) 5.5V
Number of Outputs 2
Pin Count 6
Base Part Number TLV7103318
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 585mW
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 6
Surface Mount YES
Package / Case 6-WFDFN
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
