TLV70726DQNT
RoHS
RoHS compliant
RoHS compliantPackage 4-XDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive CMOS Linear Voltage Regulator IC -40C~125C TJ 400mW 200mA 400mum
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.71544
≥100 USD $0.67936
≥500 USD $0.558096
Inventory: 1295
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 370μm
Width 1mm
Length 1mm
Height 400μm
Technical
Input Voltage Absolute-Max 6V
Min Current Limit 240mA
Dropout Voltage1-Nom 0.25V
Dropout Voltage 250mV
PSRR 70dB ~ 50dB (100Hz ~ 1MHz)
Voltage Dropout (Max) 0.3V @ 150mA
Current - Quiescent (Iq) 50μA
Protection Features Over Current, Over Temperature, Short Circuit, Reverse Polarity
Min Input Voltage 2V
Number of Regulators 1
Output Voltage 1 2.6V
Control Features Enable
Quiescent Current 25μA
Output Configuration Positive
Max Output Current 200mA
Output Type Fixed
Output Voltage 2.6V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Base Part Number TLV70726
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 400mW
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 4
Package / Case 4-XDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
