TLV70509YFPT
RoHS
/
Package 4-XFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TLV70509 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 0.92V 500mum 200mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.012
≥1 USD $1.012
≥10 USD $0.90464
≥100 USD $0.858528
≥500 USD $0.705232
Inventory: 1694
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Thickness 0m
Width 0m
Length 0m
Height 500μm
Technical
Output Voltage1-Min 0.88V
Output Voltage1-Max 0.92V
Dropout Voltage1-Nom 0.145V
Dropout Voltage 145mV
PSRR 80dB ~ 55dB (10kHz ~ 1MHz)
Voltage Dropout (Max) 0.25V @ 200mA
Current - Quiescent (Iq) 55μA
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Number of Regulators 1
Voltage - Output (Min/Fixed) 0.9V
Input Voltage (Min) 2V
Output Voltage 1 0.9V
Control Features Enable
Quiescent Current 30μA
Current - Output 200mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 5.5V
Number of Outputs 1
Current - Supply (Max) 315μA
Base Part Number TLV70509
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1
Part Status Active
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 4
Surface Mount YES
Package / Case 4-XFBGA, DSBGA
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
