TLV70233DSET
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive NO LEAD Linear Voltage Regulator IC 68dB -40C~125C TJ 555mW 300mA
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.9768
≥1 USD $0.9768
≥10 USD $0.87296
≥100 USD $0.828608
≥500 USD $0.680768
Inventory: 3533
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 6-WFDFN
Surface Mount YES
Number of Pins 6
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Subcategory Other Regulators
Power Rating 555mW
Packing Method TR
Max Power Dissipation 555mW
Technology CMOS
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TLV70233
Pin Count 6
Current - Supply (Max) 370μA
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 5.5V
Output Voltage 3.3V
Output Type Fixed
Max Output Current 300mA
Output Configuration Positive
Power Dissipation 555mW
Quiescent Current 30μA
Control Features Enable
Accuracy 2 %
Max Output Voltage 3.3V
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage 2V
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 55μA
Voltage Dropout (Max) 0.38V @ 300mA
PSRR 68dB (1kHz)
Dropout Voltage 375mV
Dropout Voltage1-Nom 0.22V
Min Output Voltage 3.3V
Power Supply Rejection Ratio (PSRR) 68dB
Voltage Tolerance-Max 2%
Min Current Limit 320mA
Output Voltage Accuracy 0.5 %
Dimensions
Height 800μm
Length 1.5mm
Width 1.5mm
Thickness 750μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
