TLV70229DBVR

Texas Instruments
RoHS
RoHS RoHS compliant
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description TLV70229 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 260mV 1.45mm 300mA -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.43648
≥100 USD $0.407616
≥500 USD $0.32604
≥1000 USD $0.30272
≥3000 USD $0.25615
Inventory: 1232
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Number of Pins 5

Technical

Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Base Part Number TLV70229
Current - Supply (Max) 370μA
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 2.9V
Output Type Fixed
Output Configuration Positive
Current - Output 300mA
Quiescent Current 30μA
Control Features Enable
Output Voltage 1 2.9V
Input Voltage (Min) 3.4V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 55μA
Voltage Dropout (Max) 0.38V @ 300mA
PSRR 68dB (1kHz)
Dropout Voltage 260mV
Dropout Voltage1-Nom 0.22V
Min Current Limit 320mA

Dimensions

Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
