TLV2217-33KCE3
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TLV2217 Tube Through Hole Over Current Over Temperature Over Voltage voltage regulator linear 400mV 500mA 0C~125C
PDF
/
Buying Options
Total Price: USD $1.93
Unit Price: USD $1.928802
≥1 USD $1.928802
≥10 USD $1.819619
≥100 USD $1.716631
≥500 USD $1.61946
≥1000 USD $1.527794
Inventory: 1210
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Technical
Operating Temperature 0°C~125°C
Packaging Tube
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Regulators
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TLV2217
Pin Count 3
JESD-30 Code R-PSFM-T3
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 12V
Output Voltage 3.3V
Output Type Fixed
Output Configuration Positive
Current - Output 500mA
Quiescent Current 2mA
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage 3V
Protection Features Over Current, Over Temperature, Over Voltage
Voltage Dropout (Max) 0.5V @ 500mA
PSRR 62dB (120Hz)
Dropout Voltage 400mV
Dropout Voltage1-Nom 0.5V
Voltage Tolerance-Max 2%
Input Bias Current 290μA
Output Voltage Accuracy 1 %
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
