TLV1117LV25DCYT
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TLV1117 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 570mV 1.8mm 1A 1.59W
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.85976
≥100 USD $0.816288
≥500 USD $0.670472
Inventory: 1105
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Surface Mount YES
Number of Pins 4
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Regulators
Power Rating 1.59W
Packing Method TR
Max Power Dissipation 1.59W
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.3mm
Base Part Number TLV1117
Pin Count 4
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 2.5V
Output Type Fixed
Max Output Current 1A
Output Configuration Positive
Quiescent Current 50μA
Accuracy 2 %
Max Output Voltage 2.5V
Output Voltage 1 2.5V
Number of Regulators 1
Min Input Voltage 2V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 100μA
Voltage Dropout (Max) 1.3V @ 800mA
PSRR 75dB (120Hz)
Dropout Voltage 570mV
Dropout Voltage1-Nom 0.57V
Min Output Voltage 2.5V
Min Current Limit 1.1A
Dimensions
Height 1.8mm
Length 6.5mm
Width 3.5mm
Thickness 1.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
