TL750L12CKC
RoHS
/
Package TO-220
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead THROUGH-HOLE Not Qualified BIPOLAR voltage regulator linear 125C 0.15A 2.54mm 600mV
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.66
≥1 USD $0.66
Inventory: 1098
Minimum: 1
-
+
Technical Details
Physical
Package / Case TO-220
Surface Mount NO
Technical
Pbfree Code no
Number of Terminations 3
ECCN Code EAR99
HTS Code 8542.39.00.01
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position SINGLE
Terminal Form THROUGH-HOLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PSFM-T3
Number of Outputs 1
Qualification Status Not Qualified
Quiescent Current 1mA
Voltage - Output 12V
Output Voltage 1 12V
Input Voltage (Min) 13V
Input Voltage (Max) 26V
Dropout Voltage 600mV
Dropout Voltage1-Nom 0.6V
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage Tolerance-Max 5%
Output Current1-Max 0.15A
Operating Temperature TJ-Max 125°C
Input Voltage Absolute-Max 26V
Adjustability FIXED
Load Regulation-Max(%) 0.12%
Line Regulation-Max (%/V) 0.04%
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
