TL1963A-18DCQT

Texas Instruments
RoHS
RoHS RoHS compliant
Package SOT-223-6
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description Active Lead Free Positive GULL WING Linear Voltage Regulator IC -40C~125C 1.5A 1.8mm 340mV
PDF
/
Buying Options
Total Price: USD $3.73
Unit Price: USD $3.7312
≥1 USD $3.7312
≥10 USD $3.3484
≥100 USD $3.165536
≥500 USD $2.743576
Inventory: 178
Minimum: 1
-
+

Technical Details

Technical

Min Output Voltage 1.8V
Voltage Tolerance-Max 3%
Min Current Limit 1.6A
Dropout Voltage1-Nom 0.34V
Dropout Voltage 340mV
PSRR 63dB (120Hz)
Voltage Dropout (Max) 0.55V @ 1.5A
Protection Features Over Current, Over Temperature, Reverse Polarity
Min Input Voltage 2.1V
Number of Regulators 1
Output Voltage 1 1.8V
Max Output Voltage 1.8V
Accuracy 3 %
Control Features Enable
Quiescent Current 1mA
Output Configuration Positive
Max Output Current 1.5A
Output Type Fixed
Output Voltage 1.8V
Voltage - Input (Max) 20V
Number of Outputs 1
Current - Supply (Max) 80mA
Pin Count 6
Base Part Number TL1963
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Dimensions

Height 1.8mm
Length 6.5mm
Width 3.5mm
Thickness 1.6mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Number of Pins 6
Surface Mount YES
Package / Case SOT-223-6
Mounting Type Surface Mount
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
