TL-SCSI285PWRG4
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Lead Free Positive GULL WING Linear Voltage Regulator IC 0C~125C 500mA 6.5mm 700mV
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.5422
≥1 USD $1.5422
≥10 USD $1.454906
≥100 USD $1.372556
≥500 USD $1.294864
≥1000 USD $1.221572
Inventory: 1540
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 6.5mm
Technical
Input Bias Current 2mA
Input Voltage Absolute-Max 7.5V
Dropout Voltage1-Nom 0.8V
Dropout Voltage 700mV
PSRR 62dB (120Hz)
Voltage Dropout (Max) 0.8V @ 620mA
Protection Features Over Current, Over Temperature, Over Voltage
Min Input Voltage 3.55V
Number of Regulators 1
Output Voltage 1 2.85V
Quiescent Current 2mA
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Output Voltage 2.85V
Voltage - Input (Max) 5.5V
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 20
Base Part Number TL-SCSI285
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TAPE AND REEL
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C
Physical
Number of Pins 20
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
