REG113NA-2.85/250
RoHS
RoHS compliant
RoHS compliantPackage SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Active Lead Free Positive GULL WING Linear Voltage Regulator IC -40C~85C 400mA 1.45mm 250mV
PDF
/
Buying Options
Total Price: USD $3.46
Unit Price: USD $3.4584
≥1 USD $3.4584
≥10 USD $3.10728
≥100 USD $2.937792
≥500 USD $2.546016
Inventory: 295
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Surface Mount YES
Number of Pins 5
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Regulators
Packing Method TR
Technology NMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number REG113
Pin Count 5
Current - Supply (Max) 1mA
Number of Outputs 1
Voltage - Input (Max) 10V
Output Voltage 2.85V
Output Type Fixed
Max Output Current 400mA
Output Configuration Positive
Quiescent Current 400μA
Control Features Enable
Accuracy 1.5 %
Max Output Voltage 2.8V
Output Voltage 1 2.85V
Number of Regulators 1
Min Input Voltage 1.8V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 500μA
Voltage Dropout (Max) 0.41V @ 400mA
PSRR 65dB (120Hz)
Dropout Voltage 250mV
Dropout Voltage1-Nom 0.25V
Min Output Voltage 2.8V
Voltage Tolerance-Max 2.3%
Output Voltage Accuracy 1.5 %
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Thickness 1.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
