REG113EA-2.85/250
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Obsolete Positive GULL WING Not Qualified Linear Voltage Regulator IC -40C~85C 400mA 3mm 250mV
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.8624
≥1 USD $0.8624
Inventory: 9069
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Output Voltage Accuracy 1.5 %
Voltage Tolerance-Max 2.3%
Dropout Voltage1-Nom 0.25V
Dropout Voltage 250mV
PSRR 65dB (120Hz)
Voltage Dropout (Max) 0.41V @ 400mA
Current - Quiescent (Iq) 500μA
Protection Features Over Current, Over Temperature
Min Input Voltage 1.8V
Number of Regulators 1
Output Voltage 1 2.85V
Control Features Enable
Current - Output 400mA
Output Configuration Positive
Output Type Fixed
Output Voltage 2.85V
Voltage - Input (Max) 10V
Qualification Status Not Qualified
Number of Outputs 1
Current - Supply (Max) 1mA
Pin Count 8
Base Part Number REG113
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology NMOS
Packing Method TAPE AND REEL
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
