REG1117A-2.5
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
REG1117 Tube Surface Mount Over Current Over Temperature voltage regulator linear 1.2V 1.8mm 1A -40C~125C
PDF
/
Buying Options
Total Price: USD $2.61
Unit Price: USD $2.6136
≥1 USD $2.6136
≥10 USD $2.35048
Inventory: 135
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Surface Mount YES
Number of Pins 4
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination SMD/SMT
ECCN Code EAR99
Subcategory Other Regulators
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.3mm
Current Rating 1A
Base Part Number REG1117
Pin Count 4
Number of Outputs 1
Voltage - Input (Max) 15V
Output Voltage 2.5V
Output Type Fixed
Max Output Current 1A
Voltage 2.5V
Max Supply Voltage 15V
Min Supply Voltage 3.8V
Output Configuration Positive
Quiescent Current 4mA
Accuracy 1 %
Max Output Voltage 2.5V
Output Voltage 1 2.5V
Number of Regulators 1
Min Input Voltage 3.8V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 10mA
Voltage Dropout (Max) 1.55V @ 1A
PSRR 62dB (120Hz)
Dropout Voltage 1.2V
Nominal Input Voltage 2.5V
Dropout Voltage1-Nom 1.2V
Min Output Voltage 2.5V
Min Current Limit 1A
Nominal Output Voltage 2.5V
Input Bias Current 4mA
Output Voltage Accuracy 1 %
Dimensions
Height 1.8mm
Length 6.5mm
Width 3.5mm
Thickness 1.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
