REG1117-3.3/2K5
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
REG1117 Tape & Reel (TR) Surface Mount Over Current Over Temperature voltage regulator linear 1.1V 1.8mm 800mA -40C~125C
PDF
/
Buying Options
Total Price: USD $2.16
Unit Price: USD $2.156
≥1 USD $2.156
≥10 USD $1.93336
≥100 USD $1.824416
≥500 USD $1.554256
≥1000 USD $1.459392
≥3000 USD $1.276986
Inventory: 545
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case TO-261-4, TO-261AA
Surface Mount YES
Number of Pins 4
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Subcategory Other Regulators
Packing Method TR
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 2.3mm
Base Part Number REG1117
Pin Count 4
Number of Outputs 1
Voltage - Input (Max) 15V
Output Voltage 3.3V
Output Type Fixed
Max Output Current 800mA
Output Configuration Positive
Quiescent Current 4mA
Accuracy 1 %
Max Output Voltage 3.3V
Output Voltage 1 3.3V
Number of Regulators 1
Min Input Voltage 3.8V
Protection Features Over Current, Over Temperature
Current - Quiescent (Iq) 10mA
Voltage Dropout (Max) 1.2V @ 800mA
PSRR 62dB (120Hz)
Dropout Voltage 1.1V
Dropout Voltage1-Nom 1.1V
Min Output Voltage 3.3V
Nominal Output Voltage 3.3V
Input Bias Current 4mA
Output Voltage Accuracy 1 %
Dimensions
Height 1.8mm
Length 6.5mm
Width 3.5mm
Thickness 1.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
