MC79L05ACDRG4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
79L05 Tape & Reel (TR) Surface Mount Over Temperature Short Circuit voltage regulator linear 1.7V 1.75mm 100mA 0C~125C
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.104122
≥1 USD $0.104122
≥10 USD $0.097812
≥100 USD $0.091502
≥500 USD $0.083926
≥1000 USD $0.080775
Inventory: 1398
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Output Voltage Accuracy 5 %
Voltage Tolerance-Max 5%
Min Output Voltage -5V
Dropout Voltage1-Nom 1.7V
Dropout Voltage 1.7V
PSRR 49dB (120Hz)
Voltage Dropout (Max) 1.7V @ 40mA
Protection Features Over Temperature, Short Circuit
Min Input Voltage -7V
Number of Regulators 1
Output Voltage 1 5V
Max Output Voltage -5V
Accuracy 5 %
Quiescent Current 6mA
Output Configuration Negative
Max Output Current 100mA
Output Type Fixed
Output Voltage -5V
Voltage - Input (Max) -20V
Number of Outputs 1
Pin Count 8
Base Part Number 79L05
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Packing Method TR
Subcategory Other Regulators
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C
Physical
Weight 72.603129mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
