LP8345CDT-1.8/NOPB
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LP8345 Tube Surface Mount Over Current Over Temperature voltage regulator linear 0.5V 6.58mm 500mA 0C~125C
PDF
/
Inventory: 7730
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 6.58mm
Height Seated (Max) 2.38mm
Technical
Output Voltage Accuracy 1.5 %
Voltage Tolerance-Max 3%
Dropout Voltage1-Nom 0.5V
PSRR 55dB (120Hz)
Protection Features Over Current, Over Temperature
Min Input Voltage 2.7V
Number of Regulators 1
Output Voltage 1 1.8V
Quiescent Current 50μA
Current - Output 500mA
Output Configuration Positive
Output Type Fixed
Output Voltage 1.8V
Voltage - Input (Max) 10V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number LP8345
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 2.285mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Technology CMOS
Packing Method RAIL
Subcategory Other Regulators
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~125°C
Physical
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
